Electronic Weighbridge Manufacturer in India

Which weighbridge suits your site

All three types weigh to the same accuracy using the same load cells and indicators. What changes is the civil work, the yard space you need and how vehicles approach the platform.

Above ground

Pitless weighbridge

Side-support beam structure mounted above ground level. The platform stays visible, so load cells, junction boxes and mounts can be serviced without entering a pit.

Choose it when

• You have straight approach length at the front and back
• Site has a high water table, rocky soil, or deep excavation is not practical
• Easy maintenance access matters more than saving yard length

Think twice if

Trucks can only enter from the front and leave from the back, so a short or side-fed yard is a poor fit.

Capacity

5–200 MT

Vehicle movement

Front and back only

Pitless weighbridge specifications

Flush mounted

Pit type weighbridge

Merely-supported beam structure fitted inside a civil pit, with only the top plate visible. The deck sits level with the yard, so no approach ramps are needed.

Choose it when

• Yard space is limited and a long straight run-up is not available
• Vehicles need to approach from the front, back and adjacent sides
• You want the whole structure enclosed in the pit for better protection

Think twice if

The pit needs waterproofing, drainage and a safe service route — plan for this before choosing pit type.

Capacity

5–200 MT

Vehicle movement

Front, back and adjacent sides

Pit type weighbridge specifications

Foundationless

Mobile weighbridge

Multi-modular platform that needs no civil foundation, supplied with or without ramps in the length and width your site requires. Built for temporary and seasonal locations.

Choose it when

• The site is temporary, seasonal or will be relocated
• You have a smooth, hard, level surface to place it on
• Civil work is not practical or not worth the spend

Think twice if

Ground condition decides accuracy — soft or uneven surfaces are not suitable.

Capacity

5–200 MT

Vehicle movement

Two-way with ramps on both sides

Mobile weighbridge specifications

Running an older mechanical system? We also handle mechanical to electronic weighbridge conversion, keeping the existing platform and civil work where it is still sound.

Standard platform sizes and capacities

Platform length is decided by your longest vehicle, and capacity by the maximum gross weight crossing the weighbridge. Graduation and load-cell count follow from both.

Weighbridges are also manufactured to customer specification where a standard size does not fit the site.

What goes into every Vepro weighbridge

More detail on load cells and digital indicators and on weighbridge software and man-less automation.

Industries we supply

• Sugar mills and cane centres
• Mining and quarries
• Cement plants
• Steel, rolling mills and foundries
• Grain mandis and rice mills
• Logistics and warehousing
• Construction and project sites
• Toll plazas and highways
• Ports and rail rake points

Alongside vehicle weighbridges, Vepro manufactures toll-plaza weigh-in-motion, rail in-motion weighing, belt conveyor weighing, tank and hopper weighing, bagging and filling machines, on-board weighers and crane scales. See the full weighing range.

Approvals and compliance

Warranty and AMC terms are finalised per project scope; a minimum one-year warranty is usually provided.

How a Vepro weighbridge project runs

1. Share your site details

   Capacity, longest vehicle, yard layout, approach length and whether you need software or automation.

2. Technical recommendation

   We advise the weighbridge type, platform size, capacity, load-cell count and graduation that suit the site, then quote against it.

3. Foundation specification

   Factory specialists specify the correct foundation for your soil condition and the right foundation type for the application site.

4. Manufacturing and testing

   High-strength platforms designed for concentrated loads using computerised stress analysis, with thorough testing and pre-assembly before delivery.

5. Installation and calibration

   Dispatch, site installation and calibration, with support for the Legal Metrology verification your site needs before trade use.

6. AMC and after-sales

   Preventive and periodical maintenance under annual maintenance contract by competent service engineers. Visits are made on demand and breakdown support is on call, through 24×7 customer care.

After commissioning, the same engineers handle calibration, AMC, breakdown repair and modernization.

Installations and proof

Vepro weighbridges are in daily use at sugar mills, mandis, cement and mining sites, steel and fabrication units, and logistics yards across Delhi NCR, Uttar Pradesh, Madhya Pradesh, Maharashtra and other regions, with installation, calibration and AMC handled by our own engineers.
